Onboard eMMC Socket (Module is purchased separately) SoC: Rockchip RK3399 CPU: big.LITTLE,Dual-Core Cortex-A72(up to 2.0GHz) + Quad-Core Cortex-A53(up to 1.5GHz)


Both boards can be booted from either TF card or an external eMMC module (purchased separately). The NanoPi M4 supports Ubuntu Desktop 18.04 (64-bit), Lubuntu l6.04 (32-bit), Ubuntu Core 18.04 (64-bit), Android 7.1 and Lubuntu Desktop with GPU and VPU acceleration. The NanoPi M4 comes in two editions with different RAM configurations. In addition, it has an RPi compatible 40-pin connector which populates dual MIPI-CSI camera interface, PCIe x2, USB2.0, eMMC socket, RTC port and etc. The NanoPi M4 has an onboard 2.4G & 5G dual-band WiFi and Bluetooth module, four USB3.0 TypeA host ports, one Gbps Ethernet port, one HDMI 2.0 Type A port, one 3.5mm audio jack and one Type-C port. Measuring only 85 x 56 mm, making this compact board an ideal platform for rapid product prototyping, including a wide selection of industrial and commercial applications. It features the same form factor as well as ports and interfaces that are compatible with Raspberry Pi 3 Model B+ SBC. The NanoPi M4 is a single board computer (SBC) based Rockchip RK3399 SoC.
